9WRO | pdb_00009wro

moderate-substrate specificity amino acid racemase

PDB DOI: https://doi.org/10.2210/pdb9WRO/pdb

Classification: ISOMERASE
Organism(s): Pyrococcus furiosus
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-09-12 Released: 2026-09-16
Deposition Author(s): Sakuraba, H., Yoneda, K.
Funding Organization(s): Japan Society for the Promotion of Science (JSPS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free:
0.194 (Depositor), 0.201 (DCC)
R-Value Work:
0.170 (Depositor), 0.183 (DCC)
R-Value Observed:
0.171 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9WRO

This is version 1.0 of the entry. See complete history.

Literature

moderate-substrate specificity amino acid racemase

Sakuraba, H., Yoneda, K.

To be published.

Macromolecule Content

Total Structure Weight: 104 kDa
Atom Count: 7,220
Modeled Residue Count: 864
Deposited Residue Count: 926
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
4-aminobutyrate aminotransferase	A, B	463	Pyrococcus furiosus	Mutation(s): 0 Gene Names: PFC_05380 EC: 2.6.1.19
UniProt
Find proteins for I6TX79 (Pyrococcus furiosus COM1) Explore I6TX79 Go to UniProtKB: I6TX79
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	I6TX79
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
LLP Query on LLP	A, B	L-PEPTIDE LINKING	C₁₄ H₂₂ N₃ O₇ P		LYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.194 (Depositor), 0.201 (DCC)
R-Value Work: 0.170 (Depositor), 0.183 (DCC)
R-Value Observed: 0.171 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 89.567	α = 90
b = 89.567	β = 90
c = 219.309	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
XDS	data reduction
MOLREP	phasing
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-09-16

Deposition Author(s):

Funding Organization	Location	Grant Number
Japan Society for the Promotion of Science (JSPS)	Japan	--

Revision History (Full details and data files)

Version 1.0: 2026-09-16
Type: Initial release
