9TAZ | pdb_00009taz

OXA-48: Q5 mutant in an acyl enzyme complex with piperacillin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free:
    0.196 (Depositor), 0.197 (DCC)
  • R-Value Work:
    0.164 (Depositor), 0.165 (DCC)
  • R-Value Observed:
    0.166 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9TAZ

Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history

Literature

Mechanistic Origins and Evolutionary Erosion of Collateral Sensitivity in a beta-lactamase.

Salamonsen, D.Buda, K.Wang, D.Gulyas, K.V.van der Kamp, M.W.Frohlich, C.

(2026) J Mol Biol 438: 169893-169893

  • DOI: https://doi.org/10.1016/j.jmb.2026.169893
  • Primary Citation Related Structures:
    9TAZ

  • PubMed Abstract:

    As antibiotic discovery stalls, exploiting collateral sensitivity, where resistance to one drug increases sensitivity to another, offers a promising route to extend the lifespan of existing drugs. However, the molecular origins and robustness of such trade-offs at the level of single resistance determinants remain poorly understood. Here, we examined a previously evolved trajectory of the β-lactamase OXA-48 to Q4 (A33V/F72L/T212A/S213A) in Escherichia coli. Compared to OXA-48, Q4 conferred 40-fold increase in ceftazidime resistance, but a 27-fold lower piperacillin resistance. This trade-off was caused by the introduction of F72L. We challenged the stability of this collateral sensitivity network by subjecting Q4 to directed evolution followed by co-selection from both ceftazidime and piperacillin. The emerging substitution V120G alleviated the piperacillin trade-off while maintaining elevated resistance to ceftazidime in genetic backgrounds harboring F72L. Structural and computational analyses revealed that evolution introduced substantial conformational changes in the Ω-loop, likely leading to less productive piperacillin binding poses. V120G counteracted the effect of F72L by decreasing the Ω-loop's conformational freedom, thereby partially restoring piperacillin resistance. Finally, we show that other substitutions at position 120 can exert similar mitigating effects. Taken together, our results provide a mechanistic understanding of how adaptive solutions both generate and erode collateral sensitivity, knowledge crucial for predicting the long-term stability of these networks.


  • Organizational Affiliation
    • Department of Chemistry, UiT The Arctic University of Norway, Tromsø, Norway.

Macromolecule Content

  • Total Structure Weight: 30.1 kDa
  • Atom Count: 2,433
  • Modeled Residue Count: 236
  • Deposited Residue Count: 244
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Beta-lactamase244Klebsiella pneumoniaeMutation(s): 4
Gene Names: blaOXA-162
EC: 3.5.2.6
UniProt
Find proteins for D6QY24 (Klebsiella pneumoniae)
Explore D6QY24
Go to UniProtKB:  D6QY24
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD6QY24
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
YPP

Query on YPP



Download:Ideal Coordinates CCD File
F [auth A],
G [auth A]
Hydrolyzed piperacillin
C23 H29 N5 O8 S
OKSUEATVFIVTFV-WBTNSWJXSA-N
JPP
(Subject of Investigation/LOI)

Query on JPP



Download:Ideal Coordinates CCD File
E [auth A]Piperacillin (Open Form)
C23 H29 N5 O7 S
CJYMHKMECTVNSA-XLMAVXFVSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
B [auth A],
C [auth A],
D [auth A],
H [auth A]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
I [auth A],
J [auth A]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free:  0.196 (Depositor), 0.197 (DCC)
  • R-Value Work:  0.164 (Depositor), 0.165 (DCC)
  • R-Value Observed: 0.166 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 91.895α = 90
b = 45.34β = 107.227
c = 64.327γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PHENIXrefinement
XDSdata reduction
XDSdata scaling
ABSphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data

  • Released Date: 2026-09-16
  • Deposition Author(s): Frohlich, C.

Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2026-09-16
    Type: Initial release
