9EF7 | pdb_00009ef7

Crystal structure of Cryptosporidium parvum N-myristoyltransferase with bound myristoyl-CoA and inhibitor 20057

PDB DOI: https://doi.org/10.2210/pdb9EF7/pdb

Classification: TRANSFERASE/INHIBITOR
Organism(s): Cryptosporidium parvum Iowa II
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): No

Deposited: 2024-11-19 Released: 2025-11-26
Deposition Author(s): Fenwick, M.K., Staker, B.L., Seattle Structural Genomics Center for Infectious Disease (SSGCID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.198 (Depositor), 0.198 (DCC)
R-Value Work:
0.168 (Depositor), 0.168 (DCC)
R-Value Observed:
0.170 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of Cryptosporidium parvum N-myristoyltransferase with bound myristoyl-CoA and inhibitor 20057

Staker, B.L., Fan, E.

To be published.

Macromolecule Content

Total Structure Weight: 105.51 kDa
Atom Count: 8,450
Modeled Residue Count: 852
Deposited Residue Count: 862
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glycylpeptide N-tetradecanoyltransferase	A, B	431	Cryptosporidium parvum Iowa II	Mutation(s): 0 Gene Names: cgd3_320 EC: 2.3.1.97
UniProt
Find proteins for Q5CV46 (Cryptosporidium parvum (strain Iowa II)) Explore Q5CV46 Go to UniProtKB: Q5CV46
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q5CV46
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MYA (Subject of Investigation/LOI) Query on MYA Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain L [auth B] MOL2 format, chain C [auth A] MOL2 format, chain L [auth B] mmCIF format, chain C [auth A] mmCIF format, chain L [auth B]	C [auth A], L [auth B]	TETRADECANOYL-COA C₃₅ H₆₂ N₇ O₁₇ P₃ S DUAFKXOFBZQTQE-QSGBVPJFSA-N		Interactions Focus chain C [auth A] Focus chain L [auth B] Interactions & Density Focus chain C [auth A] Focus chain L [auth B]
A1BHQ (Subject of Investigation/LOI) Query on A1BHQ Download Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	(2M)-2-[5-chloro-2-(piperazin-1-yl)phenyl]-N-(5-methyl-1,3-thiazol-2-yl)-1H-1,3-benzimidazole-4-carboxamide C₂₂ H₂₁ Cl N₆ O S SNVTYGYDXCJDLJ-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
1PE Query on 1PE Download Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain I [auth A] SDF format, chain P [auth B] MOL2 format, chain G [auth A] MOL2 format, chain I [auth A] MOL2 format, chain P [auth B] mmCIF format, chain G [auth A] mmCIF format, chain I [auth A] mmCIF format, chain P [auth B]	G [auth A], I [auth A], P [auth B]	PENTAETHYLENE GLYCOL C₁₀ H₂₂ O₆ JLFNLZLINWHATN-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain I [auth A] Focus chain P [auth B] Interactions & Density Focus chain G [auth A] Focus chain I [auth A] Focus chain P [auth B]
PG4 Query on PG4 Download Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain Q [auth B] MOL2 format, chain H [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain Q [auth B] mmCIF format, chain H [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain Q [auth B]	H [auth A], J [auth A], K [auth A], Q [auth B]	TETRAETHYLENE GLYCOL C₈ H₁₈ O₅ UWHCKJMYHZGTIT-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain Q [auth B] Interactions & Density Focus chain H [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain Q [auth B]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain M [auth B] SDF format, chain N [auth B] SDF format, chain O [auth B] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B]	E [auth A], F [auth A], M [auth B], N [auth B], O [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.198 (Depositor), 0.198 (DCC)
R-Value Work: 0.168 (Depositor), 0.168 (DCC)
R-Value Observed: 0.170 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.812	α = 90
b = 88.162	β = 97.62
c = 97.985	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data scaling
PHENIX	phasing
Coot	model building
PHENIX	refinement

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2025-11-26

Deposition Author(s):

Fenwick, M.K.

Staker, B.L.

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	R01 AI155536
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	6R21 AI137815-02
