8YL2 | pdb_00008yl2

Crystal Structure of Homo Tetrameric RagA-like small GTPase from Asgard Lokiarchaeota (LokiRagO) in complex with GTP

PDB DOI: https://doi.org/10.2210/pdb8YL2/pdb

Classification: HYDROLASE
Organism(s): Promethearchaeum syntrophicum
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2024-03-05 Released: 2025-09-10
Deposition Author(s): Alsheikh, F.B., Robinson, R.C.
Funding Organization(s): Vidyasirimedhi Institute of Science and Technology (VISTEC), Other private, Simons Foundation

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free:
0.230 (Depositor), 0.230 (DCC)
R-Value Work:
0.202 (Depositor), 0.205 (DCC)
R-Value Observed:
0.203 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal Structure of Homo Tetrameric RagA-like small GTPase from Asgard Lokiarchaeota (LokiRagO) in complex with GTP

Alsheikh, F.B., Robinson, R.C.

To be published.

Macromolecule Content

Total Structure Weight: 323.7 kDa
Atom Count: 19,749
Modeled Residue Count: 2,315
Deposited Residue Count: 2,736
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
GTP-binding protein	A, B, C, D, E A, B, C, D, E, F, G, H	342	Promethearchaeum syntrophicum	Mutation(s): 0 Gene Names: DSAG12_02311
UniProt
Find proteins for A0A5B9DBS5 (Promethearchaeum syntrophicum) Explore A0A5B9DBS5 Go to UniProtKB: A0A5B9DBS5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A5B9DBS5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GTP (Subject of Investigation/LOI) Query on GTP Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain K [auth B] SDF format, chain M [auth C] SDF format, chain O [auth D] SDF format, chain Q [auth E] SDF format, chain S [auth F] SDF format, chain U [auth G] SDF format, chain W [auth H] MOL2 format, chain I [auth A] MOL2 format, chain K [auth B] MOL2 format, chain M [auth C] MOL2 format, chain O [auth D] MOL2 format, chain Q [auth E] MOL2 format, chain S [auth F] MOL2 format, chain U [auth G] MOL2 format, chain W [auth H] mmCIF format, chain I [auth A] mmCIF format, chain K [auth B] mmCIF format, chain M [auth C] mmCIF format, chain O [auth D] mmCIF format, chain Q [auth E] mmCIF format, chain S [auth F] mmCIF format, chain U [auth G] mmCIF format, chain W [auth H]	I [auth A] K [auth B] M [auth C] O [auth D] Q [auth E] I [auth A], K [auth B], M [auth C], O [auth D], Q [auth E], S [auth F], U [auth G], W [auth H]	GUANOSINE-5'-TRIPHOSPHATE C₁₀ H₁₆ N₅ O₁₄ P₃ XKMLYUALXHKNFT-UUOKFMHZSA-N		Interactions Focus chain I [auth A] Focus chain K [auth B] Focus chain M [auth C] Focus chain O [auth D] Focus chain Q [auth E] Focus chain S [auth F] Focus chain U [auth G] Focus chain W [auth H] Interactions & Density Focus chain I [auth A] Focus chain K [auth B] Focus chain M [auth C] Focus chain O [auth D] Focus chain Q [auth E] Focus chain S [auth F] Focus chain U [auth G] Focus chain W [auth H]
MG (Subject of Investigation/LOI) Query on MG Download Ideal Coordinates CCD File SDF format, chain J [auth A] SDF format, chain L [auth B] SDF format, chain N [auth C] SDF format, chain P [auth D] SDF format, chain R [auth E] SDF format, chain T [auth F] SDF format, chain V [auth G] SDF format, chain X [auth H] MOL2 format, chain J [auth A] MOL2 format, chain L [auth B] MOL2 format, chain N [auth C] MOL2 format, chain P [auth D] MOL2 format, chain R [auth E] MOL2 format, chain T [auth F] MOL2 format, chain V [auth G] MOL2 format, chain X [auth H] mmCIF format, chain J [auth A] mmCIF format, chain L [auth B] mmCIF format, chain N [auth C] mmCIF format, chain P [auth D] mmCIF format, chain R [auth E] mmCIF format, chain T [auth F] mmCIF format, chain V [auth G] mmCIF format, chain X [auth H]	J [auth A] L [auth B] N [auth C] P [auth D] R [auth E] J [auth A], L [auth B], N [auth C], P [auth D], R [auth E], T [auth F], V [auth G], X [auth H]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain J [auth A] Focus chain L [auth B] Focus chain N [auth C] Focus chain P [auth D] Focus chain R [auth E] Focus chain T [auth F] Focus chain V [auth G] Focus chain X [auth H] Interactions & Density Focus chain J [auth A] Focus chain L [auth B] Focus chain N [auth C] Focus chain P [auth D] Focus chain R [auth E] Focus chain T [auth F] Focus chain V [auth G] Focus chain X [auth H]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.20 Å
R-Value Free: 0.230 (Depositor), 0.230 (DCC)
R-Value Work: 0.202 (Depositor), 0.205 (DCC)
R-Value Observed: 0.203 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 118.756	α = 90
b = 97.183	β = 104.28
c = 145.738	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Blu-Ice	data collection
DIALS	data reduction
DIALS	data scaling
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2025-09-10

Deposition Author(s):

Alsheikh, F.B.

Robinson, R.C.

Funding Organization	Location	Grant Number
Vidyasirimedhi Institute of Science and Technology (VISTEC)	Thailand	--
Other private	United States	GBMF9743 Moore Foundation grant
Simons Foundation	United States	GBMF9743
